The Indoor Transparent LED Display
Indoor transparent LED display can do advertising and branding in the area while the attention is still on the product itself. Also, natural lights and the lighting from the building can pass through, in order to save costs.
Transparent LED display applied outdoors is with high transparency from 30% to 80%, while displaying the image clearly and the natural lights can still pass through into the building. A win-win solution achieves both advertising and saving lighting costs.
Advantages of Our Indoor Transparent LED Display
Light-weight Design for easy shipping, install and maintain.
Module design. As per the best pixel pitch standard, dimension can assemble a big screen.
Easy maintenance and update. Long lifespan. Replace LED strip instead of the whole LED module for the maintenance.
High transparency.Transparency can reach up to 75%-95% with the highest resolution, screen is almost invisible when viewed from 5 meter.
High brightness. Though the energy consumption of LED is lower than projection and LCD screen,it’s still clearly visible with high brightness even directly under sunlight.
Self-heat Dissipation. With a unique design of our transparent LED display, our product will last longer and stay brighter. As heart can damage many components.
Energy Savings. Our transparent LED display uses safe and highly efficient systems, we guarantee you to save much more energy compared to regular non- transparent LED display.
| Item | Indoor P2.8 | Indoor P3.91 | Outdoor P3.91 | Outdoor P5.2 | Outdoor P7.8 |
| Pixel Pitch | 2.8-5.6mm | 3.91-7.81 | 3.91-7.81 | 5.2-10.4 | 7.81-7.81 |
| lamp size | SMD1921 | SMD1921 | SMD1921 | SMD1921 | SMD1921 |
| Module size | L=500mm W=125mm THK=10mm | ||||
| Module resolution | 176x22dots | 128*16dots | 128*16dots | 96x12dots | 64x16dots |
| Module weight | 310g 3kgs |
350g | |||
| Cabinet size | 1000x500x94mm | ||||
| Cabinet resolution | 192*192dots | 128x16dots | 128x16dots | 192x48dots | 64x8dots |
| Pixel density | 61952dots/sqm | 32768dots/sqm | 32768dots/sqm | 18432dots/sqm | 16384dots/sqm |
| Material | Aluminum | ||||
| Cabinet Weight | 6.5kgs | 12.5kgs | |||
| Brightness | 800-2000cd/㎡ | 3000-6000cd/m2 | |||
| Refresh rate | 1920-3840Hz | ||||
| Input Voltage | AC220V/50Hz or AC110V/60Hz | ||||
| Power Consumption(Max. / Ave.) | 400/130 W/m2 | 800W/260W/m2 | |||
| IP rating(Front/Rear) | IP30 | IP65 | |||
| Maintenance | Front and rear Service | ||||
| Operating Temperature | -40°C-+60°C | ||||
| Operating Humidity | 10-90% RH | ||||
| Operating Life | 100,000 Hours | ||||
