The Outdoor Rental LED Display Panel

Short Description:

Outdoor Rental LED display refers to renting a LED display that utilizes LED technology. LED has become today’s standard for display technology due to its superior brightness, color contrast and energy efficiency.

For the LED rental display, it is usually made of die-casting aluminum cabinet, the structure is light and thin, the stability is high, it i convenient to install and disassemble at any time, suitable for holding concerts and stage performances.

Outdoor rental LED display need to be moved frequently, repeatedly disassembled and installed, so the requirements for products are high, and the product shape design, structural design, material selection are all stressful. For example, if a concert is finished, it can be disassembled and transported to the other one in a limited time.


Product Detail

Parameters

Application

Video

Product Tags

Outdoor Rental LED Display23

With a convenient lightweight of 8.5k for 500x1000 cabinet, the outdoor LED display screen is easy to transport and install. Die-casting aluminum body makes it safe and stable.

The outdoor LED display screen consists of IP65 waterproof processes to ensure high quality and usage outdoors. Parts with waterproof are as followed:

●  LED Lamp
●  Power Connector
●  Signal Connector
●  PCB Board

The outdoor LED display screen contains Nationstar SMD1921 with high brightness up to 6000nits. The brightness is adjustable from 1000nits to 6000nits.

Advantages of The Outdoor Rental LED Display

Ultra Slim & Light Weight

Slim and lightweight design.

Fast lock design, fast connection.

Fast lock design, fast connection.

Concave or convex installation with curved locks.

Concave or convex installation with curved locks.

High quality CNC die-casting design, seamless splicing.

High quality CNC die-casting design, seamless splicing.

Two size cabinet design, meeting with different requirement.

Two size cabinet design, meeting with different requirement.

High refresh rate

High refresh rate and grayscale, providing excellent and vivid images.

Wide viewing angle, clear and visible images, attracting more audiences.

Wide viewing angle, clear and visible images, attracting more audiences.


  • Previous:
  • Next:

  • Item Outdoor P2.6 Outdoor P3.91 Outdoor P4.81
    Pixel Pitch 2.6mm 3.91mm 4.81mm
    Module size 250mmx250mm
    lamp size SMD1515 SMD1921 SMD1921
    Module resolution 96*96dots 64*64dots 52*52dots
    Module weight 0.35kgs
    Cabinet size 500x500mm and 500x1000mm
    Cabinet  resolution 192*192dots/192*384dots 128*128dots/128*256dots 104*104dots/104*208dots
    Pixel density 147456dots/sqm 65536dots/sqm 43264dots/sqm
    Recommended viewing distance 2m 3m 4m
    Material Die-Casting Aluminum
    Cabinet Weight 10kgs
    Brightness ≥4500cd/㎡
    Refresh rate ≥3840Hz
    Processing depth 16 bits
    Gray Scale 65536 levels per color
    Color 281.4 trillion
    Input Voltage AC220V/50Hz or AC110V/60Hz
    Imput Power Frequency 50-60Hz
    Power Consumption(Max. / Ave.) 660/220 W/m2
    IP rating(Front/Rear) IP65
    Maintenance Rear Service
    Data Interconnection Cat 5 Cable(L<100M); Multi-mode fiber (L<300M);single mode fiber (L<15km)
    Operating Temperature -40°C-+60°C
    Operating Humidity 10-90% RH
    Operating Life 100,000 Hours

    Indoor Rental LED Display22-2 Outdoor Rental LED Display22 (1) Outdoor Rental LED Display22 (2) Outdoor Rental LED Display22 (3) Outdoor Rental LED Display22 (4) Outdoor Rental LED Display22 (5) Outdoor Rental LED Display22 (6)
